2 PORT USB TO RS422/485 CONVERTER W/1.8M
USB Port | 1 x USB Type B Female (White) |
Power | 1 x DC Jack |
Serial | 2 x DB-9 Male (Black) |
Ports | 2 (Green) |
Power | 1 (Orange) |
Data Rate | 115.2 Kbps (max.) |
USB Specification | USB 1.1 Compliant; USB 2.0 Compatible |
Power Mode | Bus Powered; use of Power Adapter is optional |
Power Consumption | DC5V:0.22W:1BTU |
Operating Temperature | 0–50˚C |
Storage Temperature | -20–60˚C |
Humidity | 0–80% RH, Non-condensing |
Housing | Metal |
Weight | 0.30 kg ( 0.66 lb ) |
Dimensions (L x W x H) | 12.50 x 8.00 x 2.50 cm (4.92 x 3.15 x 0.98 in.) |
Тип | Медиаконвертор |
WDM (работа по одному волокну) | Нет |
Поддержка LFP (Link Fault Pass-through) | Нет |
Управляемый | Нет |
